Entry level Industrial grade ethernet switch COST-effective 8 port 100Mbps max. 8 port PoE output, suites for distributor OEM wholsaler indoor CCTV outdoor CCTV pur

The WPX-05F series products are flexible and can support various 10/100Mbps Ethernet media, and achieve highly stable optical fiber performance through RJ-45 interfaces.

The ZXR05F series is packaged in a compact IP40 chassis, which supports DIN rail installation as well as panel installation, thus effectively utilizing cabinet space. It is equipped with an integrated power supply, with a wide voltage range, suitable for global operation. Additionally, it provides dual redundant, reversible polarity 12V to 52V DC power input, suitable for high availability applications requiring dual or backup power input.

Interfaces:

5 ports of 10/100Base-Tx type RJ-45 interface, featuring automatic negotiation and automatic MDI/MDI-X functions.

Industrial consistency:

• 12V to 52V DC voltage, redundant power input

- Working temperature range: -40°C to 85°C

• IP40 aluminum housing

• Supports 6kV DC Ethernet electrostatic discharge protection

• Supports 6kV DC transient overvoltage test protection function, applicable to power lines.

• Free-fall, shock and vibration stability

• Embedded DIN rail and wall-mounted hardware design

Specification model: WPX-05F

10/100BASE-TX ports: 5 RJ-45 automatic MDI/MDI-X interfaces

Performance specifications: Bandwidth: 1.6Gbps; Data packet buffer: 1Mbit; Data packet forwarding rate: 1.2Mpps; MAC address table: 2K

Installation method: DIN rail

Maximum frame size: 9000 bytes; Data packet size

Flow control: Half-duplex using backpressure control, full-duplex using IEEE 802.3x pause frame

Shell: IP40 aluminum housing

LED indicator lights: Power: red; Ethernet: yellow; POE: green

Power input: 12 to 52V DC redundant power supply

Maximum power consumption: 3 watts

Surge protection: ±4KV

Network protocols: IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u; 100Base-TX/FX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x;

Network cables: 10BASE-T: Cat3, 4, 5 UTP (≤100 meters); 100BASE-TX: Cat5 or higher version UTP (≤10 meters); 1000BASE-TX: Cat6 or higher version UTP (≤100 meters)

Industry standards: FCC CFR47 Part 15, EN55022/CISPR22, Class A IEC61000-4-2 (ESD): ±8kV (contact), ±12kV (air); IEC61000-4-3 (RS): 10V/m (80~1000MHz); IEC61000-4-4 (EFT): Power port: ±4kV; Data port: ±2kV; IEC61000-4-5 (surge): Power port: ±2kV/DM, ±4kV/CM; Data port: ±2kV; IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V (150kHz-80MHz); IEC61000-4-16 (common mode conductance): 30V (continuous), 300V (1s) Certification; CE certification, FCC certification, RoHS compliance certification

Average downtime-free working time: >300,000 hours

Dimensions (width x length x height): 118 x 86 x 33.5 millimeters

Weight: Product weight: 0.36 kilograms; Packaging weight: 0.46 kilograms

Operating environment: Operating temperature: -40 to 85 degrees Celsius; Storage temperature: -40 to 85 degrees Celsius; Relative humidity: 5% to 95% (no condensation)

Warranty: Replacement of new components within 1 year; Main components 3-year warranty.
